SeisSol with GPUs

General

The current GPU version of SeisSol targets the latest NVIDIA and AMD graphics cards. Therefore, you need to have at least CUDA 11.8 or ROCm 6.0 installed in your environment. Moreover, make sure that your installed MPI implementation is GPU-aware. If you are unsure, consult the documentation of the cluster you are using.

You can also utilize UCX communication layer if you need to manually configure CUDA-Aware MPI for a cluster or your local server with an open-source MPI implementation e.g., OpenMPI.

GPU version of SeisSol follows single rank/single GPU strategy. Therefore, if you want to run SeisSol on M nodes where each node is equipped with N GPUs then make sure that you launch SeisSol with M x N MPI processes.

To achieve the most efficient CPU-to-GPU communication and vice versa you have to pin your MPI processes to CPU cores which are the closest to the target GPUs. This problem is also known as GPU affinity. Latest versions of workload managers (e.g. SLURM) are aware of this problem and try to provide an automatic, GPU-aware process pinning. Consider the following SLURM options:

  • --ntasks-per-gpu

  • --gpu-bind

You can also enforce good GPU affinity with rankfiles if your GPU cluster or local server does not use a workload manager but is equipped with multiple GPUs per node.

Process Pinning

Correct process pinning of 4 MPI processes where each process controls 3 OpenMP threads and one communication thread.

Some systems have complex numbering of processing units and/or NUMA domains. Sometime it is very difficult to achieve desirable pinning of the communication and/or output-writing threads with HPC resource managers like SLURM. Therefore, SeisSol provides SEISSOL_FREE_CPUS_MASK environment variable which helps to describe locations of the auxiliary threads per local MPI process. The variable accepts a comma separated list of elements where an element can be either 1) an integer, or 2) a range of integers defined as [start, end] or 3) a comma separated list of integers surrounded by the curly brackets. The i-th list element describes the free cpus locations for the i-th local MPI process.

# SEISSOL_FREE_CPUS_MASK="(int | range: <int-int> | list: {int,+})+"
# Examples,
export SEISSOL_FREE_CPUS_MASK="24,28,32,36"
export SEISSOL_FREE_CPUS_MASK="24-27,28-31,32-35,36-39"
export SEISSOL_FREE_CPUS_MASK="{24,25},{28,29},{32,33},{36,37}"

# Note, it is allowed to mix the formats of list elements. For example,
export SEISSOL_FREE_CPUS_MASK="24,28-31,{28,29},36"

Supported SeisSol features

  • acoustic and elastic (isotropic, anisotropic) wave propagation models

  • kinematic point sources

  • dynamic rupture (all friction laws)

  • off-fault plasticity model

Experimental branches include support for visco-elastic wave propagation as well.

Compilation

To start off, make sure that you already have GemmForge installed on your system. If you don’t have then follow this link.

After that, get the latest version of SeisSol

git clone --recurse-submodules https://github.com/SeisSol/SeisSol.git seissol-gpu

Compile SeisSol with (e.g.)

mkdir -p seissol-gpu/build && cd seissol-gpu/build
cmake -DDEVICE_BACKEND=cuda -DDEVICE_ARCH=sm_70 -DHOST_ARCH=skx \
-DCMAKE_BUILD_TYPE=Release -DPRECISION=double ..
make -j

The following two CMake options can be useful to improve performance:

  • USE_GRAPH_CAPTURING: enables CUDA/HIP graphs. These are used to speed up the kernel execution for wave propagation equations.

  • PREMULTIPLY_FLUX: enables the pre-multiplying of flux matrices (it was disabled for CPUs to free up cache space). This usually results in a speedup for AMD and Nvidia GPUs. By default, it is switched on when compiling for an AMD or Nvidia GPU and switched off in all other cases.

  • DEVICE_EXPERIMENTAL_EXPLICIT_KERNELS: enables a hand-written kernel to speed up some internal, heavily memory-bound computations. Enabled for AMD and NVIDIA GPUs by default; but it works on all others as well.

Execution

The launching process of the GPU version of SeisSol is similar as the one of the CPU version.

mpirun -n <M x N> ./SeisSol_dsm70_cuda_* ./parameters.par

It is important to know that the GPU version of SeisSol by default allocates 1GB of GPU memory at the beginning of SeisSol execution. It is necessary for fast allocation/deallocation of GPU memory needed for holding temporary data. The default value can be changed by setting a necessary one to DEVICE_STACK_MEM_SIZE environment variable. For example, the following will force SeisSol to allocate 1.5GB of stack GPU memory for temporary data:

export DEVICE_STACK_MEM_SIZE=1.5
mpirun -n <M x N> ./SeisSol_dsm70_cuda_* ./parameters.par

The following device-specific environment variable is supported right now:

  • SEISSOL_PREFERRED_MPI_DATA_TRANSFER_MODE

Currently, SeisSol allocates MPI buffers using the global memory type. Some MPI implementations are not GPU-aware and do not support direct point-to-point communication on device buffers. SeisSol provides the SEISSOL_PREFERRED_MPI_DATA_TRANSFER_MODE environment variable that can be used to select the memory type for the buffers. The host value means that the data will be copied to/from the host memory before/after each MPI_Isend / MPI_Irecv. The default value is direct which copies the data out of the GPU buffers directly.

Data Flow Diagram
